Environment Protecting Concrete batching plant

Environment Protecting Concrete batching plant

Concrete mixing Plant

  • Brand Name:Haomei Machinery
  • Type:HZS180-1Q3000
  • Port:Any port in China

Get lastest price

  • Environment Protecting type Concrete batching plant developed based on the designing of HZS120-1Q2000 and HZS90-1Q1500 concrete batching plant of our company, and absorbed the advanced technology all over the world. It’s the most automatic and highest concrete batching plant of domestic.The concrete batching plant has the characteristics of Structure Simple, multiple functions, low cost. The rated capacity of the concrete batching plant is 150-180m3/h (normal concrete), the concrete mixer is MAO4500/3000 twin-shaft concrete mixer, it can be used to produce the Low slump, harsh, plastic, Lightweight concrete and motar. The equipment is ideal for water conservancy, electricity, metallurgy, mine, ports, bridge, urban construction project etc. Especially ideal for the producing of urban commercial concrete. Characteristics of the concrete batching plant: 1. compact layout, man-machine engineering design. 2.Computer Automatic Control System, automatic for all the produce process include batching, weighing, mix, output. With the function that CRT color display, input and output Monitoring and prestore 200 types of batching. Make it reality that adjust before batching, automatic compensation for the owed weight, deduct the excess weight, and print, statistic, record etc. High automaticity, advanced technology, In the international leading level. 3.Equiped Italy MAO4500/3000 two-shaft concrete mixer. 4. The design of pneumatic system fully considered the stability and working life of the gas purification, oil mist dispose valve, cylinder layout, air filter, mist dispose, solenoid valve etc. 5.Used new type one sided color pressure plate, the color can be choosed.

    1.2 conditions of usage The equipment can be used in the condition as follows: 1. Environment temperature -10°~+40° 2. Wind load Less than 700pa 3. Snowd load Less than 800pa 4. Altitude Less than 2000m 5. Power supply Power 220/380V±10%, 50HZ The pressure of air compressor -10°~+40° 1.3 Main specification (single plant) 1. Rate capacity 150~180 m3/h 2.Mixer two-shaft Capacity (packed) 3m3 Power 2×55Kw 3.horizontal belt conveyor
      Convey capacity 600t/h
       Belt width 1000mm     Blet speed 2m/s 4. Feeding belt conveyor
       Convey capacity 900t/h     Belt width 1000mm Blet speed 2.5m/s 5. Batching and weighing equipment Aggregate weighing (3 sets) 3500Kg weighing accuracy ±2% Sand weighing (2 sets) 3500Kg weighing accuracy ±2% Cement weighing 1800Kg weighing accuracy ±1% Coal ash weighing 800Kg weighing accuracy ±1% Water weighing 800Kg weighing accuracy ±1% Additive weighing 80Kg weighing accuracy ±1% 6.Screw conveyor Diameter Φ325mm (3 sets) Capacity 110T/h
    Power 22Kw
    Diameter Φ273mm (2 sets)
    Capacity 80T/h
    Power 18.5Kw
    7. Control system electric-pneumatic Concentration computer automatic control
    8.power supply three-phase alternating current 380/220V 50HZ
    9. Working pressure of air compressor 0.6~0.7Mpa
    10. Discharge hopper Discharge height 4150mm
    11. Total power ~310kw
    1.4 external system

    type 240 270
    1 Productivity (m3/h ) 200~240 225~270
    2 Capacity of Mixer (m3) 4 4.5
    3 batch weigher
      Stone said(kg) 4800 5400
      Sand said(kg) 4800 5400
      cement weigher(kg) 2200 2400
      Fly ash and slag said that(kg) 1200 1350
      Additive said(kg) 100 120
      The water said(kg) 1200 1350
    4 Belt width(mm) 1200 1200
    5 Total power 320kw 340kw



    Environment Protecting Concrete batching plant
