Concrete Mixer Truck 8m³ -haomei machinery-

Product Overview Features and Applications Strength Packaging and Delivery

Product Overview

Haomei series mixer truck adopts European modern style, featuring attractive appearance, rational structure and stable performance. Different steel materials for different parts of tank body, which is made from China famous steel factories. Service life is 1.5 times than average.
Adopt CNC plasma equipment and leading international fixtures, ensure the accuracy of the parts manufacturing key weld using CNC automatic welding production lines to ensure the weld strength. Modular design and assembly line keeps product quality consistency. Structure parts adopt blasting pretreatment process; Painting work used luxury coach paint process, completely in accordance with the coating process of industry leading technology, effectively guarantee the quality of the vehicle.
Haomei series truck mixer covers mixing capacity 6-16m³ all volume products, mainly adopts
HOWO/SINOTRUK/NISSAN/HINO/FOTON/DFM-Dongfeng/FAW-Jiefang, etc. Special upper tank projects for special chassis, to make each other match reasonable.

Model	HM8-D
Specification	Unit	Value
Mixing Capacity	m³	8
Tank Volume	m³	12.8
Feeding Speed	m³/min	≥3
Discharging Speed	m³/min	≥1.5
Residual Ratio of Discharging	%	≤0.5%
Water Supply System		Air pressure
Water Tank Volume	L	260
Overall Dimension	mm	871524963800
Chassis Model		HOWO
Clutch	φ	φ430 Monolithic dry type
Min Ground Clearance	mm	314
Max Speed	km/h	90
Engine Max Output Power	kw	276
Emission Standard		Euro Ⅲ
Rated Load	kgs	13500
Overall Weight	kgs	25000
Wheelbase	mm	3225+1350

Features

1. High-intensity drum material, featuring better wear-resistance and long service life;
2. Optimized mixing blades, low material residue;
3. High-quality parts, reliable running;
4. Excellent performance and convenient operation;
5. Imported original hydraulic system

Applications

Wide range of application especially for mass concreting works like Construction of Canals, Bridges, Highways, Dams, Multistoried & Industrial Buildings, Factories, and Airports for ready mixed concrete works.

Why Choose Haomei Machinery.

Technologies:Top polishing technology guarantees good luster and smooth surface.
Markets:Obtain market sharing all over the world.
Equipment:Advanced cutting line to provide a wide range of specifications.
Production capacity:25 to 180m3/h.can be customized to meet any demand of the products raised by our customers.
Employees:Over 25 sale persons to provide good service for customers.
Responsibility: Engaged in charity donation and provide eco-friendly products.

Packaging and Delivery of Haomei.

1. Standard seaworthy container 20 GP or 40 GP ,40 HQ according to configuration ;
2. With wires for fastening the machine and frame structure inside the container ;
3. The electric items and installation components packed with strong and standard packages.
