Single Shaft Concrete Mixer

Download Product Manual (PDF file)
wade@haomei.biz Get samples and prices !

Cut to size at customers' need !

Add to Product Favorites
Share
Product Overview

Single Shaft Concrete Mixer is a new and multi-function compulsory mixer. This single shaft mixer is used to mix dry concrete, plastic concrete, fluid concrete, lightweight aggregate concrete and various mortar. Our Single Shaft Concrete Mixer can be used solely to undergo concrete mixing and production. In addition, it can make great contributions to the construction of roads, bridges, wharves, small and medium-sized concrete prefabricated plants.

Twin Shaft Concrete Mixer worm gearing offers maximum operational reliability and a long service life – even when exposed to extreme loads. The gearboxes are directly mounted on the mixing shafts without a rigid connection to the mixing trough. With the selected material pairing, BHS Twin Shaft Concrete Mixer worm gearing compensates the load changes that occur every time the mixer is charged.

Model JDC350 JDC500 JDC1000
Charging Capacity (L) 560 800 1600
Discharging Capacity (L) 350 500 1000
Productivity (m3/h) 18 25 50
Aggregate Size (mm) 80/60 80/60 80/60
Rev of Drum (r/min) 28 24 24
Complete Machine Power (KW) 19.55 24.75 44
Mixing Time (s) 30 30 30
Overall Dimension (LXWXH) (mm) 2580X2340X2850 2600X2789X3200 3370X2789X3650
Dragged Speed (m/h) 20 18 18
Overall Weight (kg) 3300 4000 6100

Single shaft mixer consists of feeding system, mixing system, mixing system, transport system, discharging system, water supply system, rack and electrical control system and other components. The feeding system adopts tonnage hoist, so it has fast feeding speed. The mixing system of this single shaft mixer is made of wear-resistant alloy iron, which prolongs the service life. The motor of transport system of this single shaft concrete mixer is directly installed on a fixed chassis, and the power reducer and the coupling cause the mixing shaft to rotate and mix. The water is sprayed directly to the mixing shaft and side liner in the water supply system, so it has features of simple structure, evenly spraying and good cleaning effect.

The mode of the discharging device is the mechanical, and it can be operated in the control box. In addition, the discharging device of the single shaft concrete mixer and mini concrete mixer adopt turbine deceleration, which can reduce the cost of labor, time and construction investment. Rack is composed of chassis, legs, walking tires, and it has the features of easy operation and stable performance. The whole concrete mixer has relatively light weight and small footprint, which can be transferred easily to different construction sites, and it greatly saves the cost of materials and operators. The electric control system consists of five switches and control box, which is really convenient to operate.

Features

1. Simple structure and stable performance. The structure of the single shaft concrete mixer is very simple, and it has stable performance in the operation.
2. Good mixing quality and high production efficiency. This single axle concrete mixer has strong mixing effect as big cement mixer, which can be completed in a short time.
3. Low energy consumption and operation noise. This single batch concrete mixers adopt advanced technology, which has the features of low energy consumption and less noise.
4. Good wear resistance and long service life. Liner and blade of this single shaft concrete mixer are made of wear-resistant materials, and it has a good resistance and long service life.
5. Easy to install and disassemble. It is very convenient to move the single shaft mixer from one site to another site in concrete construction wite like mobile concrete mixer for sale.
6. Brand assurance and cost-effective. The main components of this single shaft mixer are made of famous brand, which has characteristics of high quality and reasonable price.

Why Choose Haomei Machinery.
  • Technologies:Top polishing technology guarantees good luster and smooth surface.
  • Markets:Obtain market sharing all over the world.
  • Equipment:Advanced cutting line to provide a wide range of specifications.
  • Production capacity:25 to 180m3/h.can be customized to meet any demand of the products raised by our customers.
  • Employees:Over 25 sale persons to provide good service for customers.
  • Responsibility: Engaged in charity donation and provide eco-friendly products.
Packaging and Delivery of Haomei.

1. Standard seaworthy container 20 GP or 40 GP ,40 HQ according to configuration ;
2. With wires for fastening the machine and frame structure inside the container ;
3. The electric items and installation components packed with strong and standard packages.

  • Concrete-plant Packaging
  • Concrete-plant Packaging
  • Concrete-plant Packaging
  • Concrete-plant Packaging
FAQ
  • 1. How does JS500 Concrete Mixer work?
    The JS500 Concrete mixer is a double-shaft forced concrete mixer. Through reasonable design, the mixing efficiency is high, and the quality of the stirred concrete is fine and uniform. But how does JS500 concrete mixer work? Do you know?
    1. Feeding sand and gravel loading is manual feeding, small dump truck picking up; water is pumped by the JS500 mixer water pump to the top tank, and the water is manually operated; the cement is directly dumped into the mixer hopper by manual unpacking.
    2. The weighing sand and gravel are weighed by the weight of the manual push trolley; the cement is measured by 50kg per pack; the water is quantified by the water tank scale. Weighing error: 2% for cement, 3% for sand and stone, and 2% for water admixture.
    3. The aggregate sand and cement are poured into the hopper of the mixer. The wire rope pulling hopper climbs upwards. When climbing to a certain height, the hopper enters the loading frame, the door is automatically opened, and the material is discharged into the mixing drum through the funnel while pushing the sluice enters the water.
    The material is generally mixed for 58s. When the concrete mixture is stirred evenly, it can be discharged.
    The mixer is the bottom opening and unloading, which avoids the tilting of the mixing drum, which is safe and labor-saving, and simplifies the structure. The arrangement is more compact and reasonable. The concrete falls into the transport trolley and is sent to the on-site pouring place.
    The use of the JS500 mixer alone requires a lot of manual participation. It is recommended that you can use the PLD800 concrete batching machine together to achieve automation, greatly improve productivity, and be safe and reliable.if you want more information, please email wade@haomei.biz
  • 2. What is the price of your concrete mixer?
    We have listed the price range of all our concrete mixers on this website for your reference. The final price is affected by multiple factors such as raw materials, exchange rates and freight. If you intend to purchase, please leave us a message and we will update the price for you.
